Magnetic Pogo Pin Connector 6-Pin /High Quality Price Concessions

Product Name：Magnetic connector-SM 100 6-PIN

Delivery time: 48 hours to send samples

Daily output: 100,000 sets

E-mail: [email protected]

(I'm online, contact me now!)

Inquiry

Overview
Inquiry
Related Products

1、2.2mm pitch magnetic pogo pin connector

As one of the top 3 manufacturers in the field of magnetic connectors in China, the 6-PIN bent magnetic connector we launched has a 2.2mm precision pitch and a compact length of 25mm, which perfectly solves the wiring problems of miniaturized devices. The contacts are made of brass substrate + 1.5μm gold plating, with a maximum contact resistance of 50mΩ, supporting 3A stable current and 12V voltage transmission, and a plug-in life of over 30,000 times (verified by the EIA-364-09 standard). The entire series of halogen-free and lead-free materials have passed ROHS/REACH/CE certification and are compatible with EU EN 50581, US UL 2238 and Japanese JIS C 6950 standards.

6 reasons why global customers choose us:
China's TOP3 production capacity guarantee: 500,000 pieces per day, 100% on-time delivery rate
Nano-level quality control: German Zeiss three-coordinate full inspection (±0.015mm tolerance) + X-ray coating analysis
Agile response: 48-hour sample delivery, support for deep customization of PIN position/magnetic pole direction/shell material
Technical empowerment: free provision of 3D STEP models, magnetic force distribution simulation data and welding process packages
Dual certification: ISO 13485 medical equipment/IATF 16949 automotive electronics production line certification

Applied in consumer electronics, medical equipment, automotive electronics, roboHigh quality and affordable
ITEM	DATA #1
Model	SM-100 6-Pin
Metallic materials	Brass C6801
spacing	2.2mm
Magnet	N52
Rated current	3A
Mechanical life	30,000 cycle Min
Salt spray test	48H
Suction force	500±20%
Housing	Halogen-free lead-free insulating plastic
Material and coating conform to ROHS and REACH standards

3、Pogo pin magnetic connector scheme can be customized according to your requirements.

1. Shape and structure: round, square, long strip, runway, etc.

2. Wire materials: PVC, TPE, silica gel, etc.

3. Wire shape: round wire, braided wire, flat wire, etc.

4. Waterproof grade: up to IP68.

5. Suction: 150g-3000g.

6. Rated voltage / current: ≤ 120V, ≤ 40A.

7. Connection method: 90 °, 180 °or other angle.

8. Replacement ability: Ihammer O adapter, USB2.0/3.0, HDMI, RJ45, D-SUB, pin busbar, DC Jack, etc.

9. Mother end assembly style; DIP, 90 °bending, welding wire, glue wrap molding, etc.

10. Mother end positioning mode: concave and convex groove, sealing ring, clamping lock, positioning ear, positioning column, in-mold injection molding.

Let us be your most reliable supplier!
