Electronic Pins 12V 0.5A Current | Pogo pad Supplier
Product Name：RG 1030-12p
Daily output: 500,000 pieces
Delivery time：5 to 15 days
E-mail: [email protected]
- Overview
- Inquiry
- Related Products
1.Electronic pins 12V 0.5A current
Small dip-style pogo pin, overall height 6mm, 0.5A low current, service life 10,000 times, salt spray test 48H, lead-free brass gold-plated material, materials and coatings comply with ROHS and REACH standards
In terms of environmental protection, all our product lines use halogen-free and lead-free materials and have passed ROHS and REACH certifications.
In terms of delivery time, our company produces 100,000 spring pins per day, and the fastest delivery time is five days
In terms of company strength, we have 15 years of experience in the research and development and production of pogopins. We have developed over 2,000 products so far. Our mature experience and equipment can ensure product quality
3、What are the advantages of choosing our pogo pins
100% environmentally friendly materials that meet RoHs and REACH requirements.
Automatic riveting press assembly, automatic inspection and shipment.
Tolerances can be controlled to ±0.01mm.
Contact impedance ≤ 15m Ω.
The life span can reach more than 1000000 times.
No mold opening, convenient customization, cost saving.
The elasticity can be adjusted according to the requirements.
7-day flexible customized production cycle, simultaneous provision of EMC protection optimization solutions and failure analysis services, to help you build a zero-defect supply chain system at a lower overall cost. ISO-certified factory production, complete material reports, environmental certification and 3D drawings are provided with the goods to help customers quickly pass product compliance reviews.
4、pogo pins parameters：
| ITEM | DATA #1 |
| Model | RG-1030-12p |
| Metallic materials | Brass C6801 |
| PIN electroplating | Customized to your needs |
| Rated current | 0.5 A |
| Mechanical life | 10,000 cycle Min |
| Material and coating conform to ROHS and REACH standards | |
