Pogo Connector

Dongguan Xinteng Electronics Co., Ltd. is one of the most reliable manufacturers and suppliers of Pogo Connector in China, featured by quality products and good service. Welcome to wholesale bulk durable Pogo Connector in stock here from our factory. Also, customized service and OEM&ODM service are available.

This pogo connector features a circular docking structure with four evenly spaced Pogo pins spaced 3.5mm apart, creating a balanced layout. This design offers the advantage of stable contact within confined spaces while also facilitating sealing. Both the material selection and structural design of this connector demonstrate reliability and stability. The blister plate ensures precise positioning, the Pogo pins provide a stable current connection, and the plastic shell provides insulation and protection. Ideally suited for small devices requiring high-temperature assembly, plug-in/plug-out resistance, and reliable conduction, this Pogo connector solution offers excellent cost-effectiveness and stability.

This small, high-current, circular Pogo connector features an 11.12mm diameter, 5A single-pin current rating, 18V DC rated voltage, 3.5mm pin spacing, and a temperature resistance of up to 260°C. This type of connector is commonly used in high-reliability, low-power devices such as medical equipment, portable testing devices, smart charging docks, and outdoor electronics.

Dongguan Xinteng Electronics is a leading pogo pin manufacturer in China. Our products are widely used in humid, high-temperature, low-temperature, and micro-space applications, offering advantages in high current, miniaturization, stability, long lifespan, high reliability, and corrosion resistance, making them perfectly suited for extreme environments.

• China's first supplier of non-invasive EEG sensor connection modules
• Factory capable of mass-producing 40A high-current pogo pins
• Manufacturer achieving 1 million cycles of compression mechanical life
• China's professional supplier of charging connection modules for medical, consumer electronics, and specialized industries

The most notable features of pogo connectors are their compact size and high current carrying capacity, along with their highly precise and reliable internal structure.

Blister Tray

The blister tray primarily serves for positioning and support. Made of high-temperature resistant, solder-resistant transparent PET material, it can withstand reflow soldering at 260°C without deformation. The blister tray typically features slightly raised circular grooves to secure the four pogo pins and prevent displacement under high temperatures or vibration. Furthermore, its flat bottom surface allows for contact with the PCB pads, ensuring a stable installation and preventing warping.

Pogo Pins

Their internal structure is a typical high-current design, primarily composed of pins, insulating beads, springs, and pin tubes. The pins and pin tubes are plated with a 0.5µm thick gold layer, and the springs are plated with a 0.025µm thick gold layer. The spring pins have passed a 48-hour salt spray test and exhibit a contact resistance as low as 50mΩ.

The spacing between each pogo pin is 3.5mm, ensuring electrical safety clearance while maintaining a compact layout within the circular structure.

Plastic Housing

The plastic housing encases the pogo pins, providing insulation, dust protection, and shock resistance. It also boasts high hardness, abrasion resistance, and high-temperature resistance, making it particularly suitable for interfaces requiring frequent plugging and unplugging. The inner wall of the plastic housing is securely attached to the blister tray via snap-fit ​​or heat-shrink connection, eliminating the need for additional screws and saving space.
